YS-686茶叶包装机
特 点 Characteristic
1、 本机适用于茶叶、药茶、保健茶、咖啡等小颗粒物的一次性包装。
The machine is suitable for one-time packing of small particles such as tea,medicinal tea,health tea,coffee and so on.
2、 采用温控器控制封口温度，可保证封口平整，提高成品率。采用PLC控制器控制整机动作，触控式荧幕操作界面，操作方便。
The sealing temperature controller is adjusted by PID,ensure each sealing is flatly, increase the yield .Overall machine movement was controlled by PLC, touch sereen operation interface， easy to operate.
3、 具有计量准确、操作简单
High capacity，accurate measuring，easy operation.
4、 包装材料：聚丙烯/聚乙烯，铝箔/聚乙烯，镀铝/聚乙烯等。
Packing material：BOPP/Polyethylene, Aluminium/Polyethylene, /Plated alumnium/Polyethylene and so on.
技术参数Technical Parameters
计量范围：1 - 10g
Measuring Scope
预置袋尺寸：长（L）85~150mm
Bag size 宽（W）50~60mm
包装速度：7- 15 bags/min
Packing Speed
外型尺寸: 685*700*1375mm
Dimension ( L * W * H )
整机重量：150kg
Weight
总 功 率：AC220V / 50HZ / 2KW
Toal power
